Airsal gasket set cylinder 47 mm Puch

Airsal 47 mm cylinder kit angled exhaust | Puch

Manufacturer: Airsal · Material: Aluminum · Surface: sandblasted · Area of application: Tuning · Displacement: 75 ccm · Nominal diameter: 47 mm · Crankshaft stroke: 43 mm · Number of fixing points: 4 pcs · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 38 mm · Ø piston pin (B): 12 mm · Hole spacing outlet: 42 mm · Outlet type: slanted · Thread outlet: M6x1 (standard thread) · Hole pattern [mm]: 44 x 44 · Camouflaged: No

Airsal 47 mm cylinder kit (straight exhaust) | Puch

Manufacturer: Airsal · Material: Aluminum · Surface: sandblasted · Area of application: Tuning · Displacement: 75 ccm · Nominal diameter: 43 mm · Crankshaft stroke: 43 mm · Ø cylinder neck: 51 mm · Number of fixing points: 4 pcs · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 38 mm · Ø piston pin (B): 12 mm · Hole spacing outlet: 42 mm · Outlet type: straight · Thread outlet: M6x1 (standard thread) · Hole pattern [mm]: 44 x 44 · Camouflaged: No

Gas cable Ø 1.25 mm x 220 cm (cylindrical nipple) Bing

Ø Stranded wire: 1.25 mm · Nipple shape: Cylinder · Ø nipple: 3 mm · Nipple length: 5 mm · Manufacturer: Made in Germany · Material: Steel · Surface: galvanized (blue) · Number of components: 1 pcs · Cable length: 2200 mm · Area of application: Standard

Fuel tap horizontal M12x1 (with union nut) outgoing at the bottom

Possible lever positions: open / closed / reserve · Material lever: Metal · Thread type: MF12x1 (fine pitch thread) · Filter type: Plastic net · Installation direction: horizontal / horizontal · Outlet direction: below · Spare tube shape: curved · Ø fuel hose connection: 6 mm · Reserve level: 70 mm · Mounting type: Union nut

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Contents [ml]: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Area of application: Gearbox lubrication with clutch · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

swiing® revival stud bolt set M6 x 106 mm | Puch

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Diameter: 5.9 mm · Drive: External hexagon · Thread type: M6x1 (standard thread) · Thread length: 13 mm · Thread length: 18.5 mm · Total length: 106 mm · Width across flats SW: 10 mm · Alternative version of the Puch OEM number: 360.1.10.034.1

MBR 0.5 mm lifting plate Gilardoni italkit Inox | Puch

Manufacturer: MBR · Place of use: Cylinder base · Material: Chrome steel (known as Nirosta®) · Area of application: Tuning · Ø cylinder: 47 mm · Thickness: 0.5 mm

Airsal piston 47 mm | Puch

Manufacturer: Airsal · Nominal diameter: 47 mm · Ø outside piston (A): 46.95 mm · Compression height (C): 22.35 mm · Curvature (D): 3.7 mm · Total piston height (E): 50.1 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1 mm · Ø piston pin (B): 12 mm · Piston weight: 108 g

Polini brake shoes Ø 80 x 18 | Puch Maxi

Slotted: No · Manufacturer: Polini · Ø drum: 80 mm · Color: silver · Springs included: Yes · Number of springs: 2 pcs · Ø locating bolt: 10 mm · Width: 18 mm · Area of application: Tuning

swiing® revival gasket gearbox cover engine 1 mm | Puch E50

Ø inside: 106 mm · Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Thickness: 1 mm · Number of fixing points: 4 pcs · Ø outside: 116 mm · Alternative version of the Puch OEM number: 349.1.10.349.1

Oil seal FPM 17/40/7 DUO | Puch E50

Simmering type: A DUO - With rubberized outer casing / two sealing lips. · Ø inside: 17 mm · Manufacturer: Puch · Material: FPM - Fluororubber · Surface: rubberized · Width: 7 mm · Temperature resistance (min.): -30 - 200 °C · Ø outside: 40 mm · Area of application: Standard
