Black cylinder head cover in the 38 mm version, compatible with your Puch Maxi S / N, Supermaxi LG1 / LG2, as well as your X30 Sport NS / NL moped with E50 / ZA50 (air-cooled) / ZA50 (catalytic converter) or Z50 engine.
The gray combustion chamber cover is perfectly suited for the corresponding AKOA 38 mm cylinders as well as for other 50 cc cylinders. The original design is harmoniously echoed by the cast-in Puch stamp on the underside.
Please note that there is no decompression hole.
You can find the matching cylinder head gasket, installation hardware, and our recommended spark plugs in the accessories section.
Brand-name product from the manufacturer AKOA.
Original Puch part number: 349.9.10.001.1
| Manufacturer | AKOA |
| Camouflaged | No |
| Material | Aluminum |
| Surface | varnished |
| Ø cylinder | 38 mm |
| Width | 123.2 mm |
| Height | 54.5 mm |
| Hole pattern [mm] | 44 x 44 |
| Number of fixing points | 4 pcs |
| Candle thread | short |
| Decompressor | No |
| Total length | 132.2 mm |
| Area of application | Standard |
| Puch | E50 ZA50 (air-cooled) Z50 (X30 Sport) |
