Toolbox | Piaggio Ciao PX

CIF Clamping screw front brake | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: CIF · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Thread type: M7x1 (standard thread) · Number of components: 6 pcs · Drive: External hexagon · Ø outside: 11 mm · Screw head: Hexagon · Total length: 25 mm · Thread length: 19.5 mm · Width across flats SW: 11 mm

Pedals angular | Piaggio Ciao. SI, Bravo

Material: Plastic · Surface: ribbed · Thread type: FG14.3 (9/16" 20G) · Color: black · Drive: Outer edge · Total length: 118 mm · Width: 51 mm · Reflectors: Yes · Height: 29 mm · Width across flats SW: 15 mm

swiing® revival screw footboard / headlight Inox | Piaggio Ciao P, SC, PX

Ø External head: 13.8 mm · Manufacturer: swiing® revival parts · Material: Chrome steel (known as Nirosta®) · Thread type: M6x1 (standard thread) · Drive: Slot · Screw head: Lens head · Total length: 17 mm · Piaggio OEM number: 102986 · Piaggio OEM number: 259349

Lockable fuel filler cap | Piaggio Ciao

Ø External head: 54 mm · Material: Plastic · Color: black · Fuel filler cap: Plug 33 mm · Lockable: Yes · Vented: Yes · Height: 105 mm

CIF screw set side protection | Piaggio Ciao

Manufacturer: CIF · Material: Spring steel · Area of application: Standard · Material: Steel · Surface: galvanized (blue) · Surface: raw · Color: silver · Number of components: 12 pcs · Drive: Slot · Screw head: Lens head

Emblem "Piaggio" Ø 30 mm steering head | Piaggio Ciao

Manufacturer: Made in Italy · Material: Aluminum · Diameter: 30 mm · Rear side texture: Adhesive · Mounting type: glue · Piaggio OEM number: 574771

Splash guard front fender | Piaggio Ciao

Manufacturer: Made in Italy · Material: Rubber · Color: black · Total length: 115 mm · Number of fixing points: 2 pcs · Ø mounting hole: 3.3 mm · Width: 90 mm · Mounting type: Rivets · Piaggio OEM number: 100446

GPO Support rubber fork swing arm | Piaggio Ciao

Manufacturer: GPO · Material: Rubber · Color: black · Ø outside: 7.9 mm · Ø mounting hole: 6.9 mm · Total length: 22.8 mm · Width: 16.25 mm · Height: 8.8 mm · Total height: 22.7 mm

GPO spring guard black | Piaggio Ciao SC, PX

Material: Plastic · Color: black · Total length: 50 mm · Width: 57 mm · Height: 85.5 mm · Manufacturer: GPO · Piaggio OEM number: 247847
