Motor cable routing | Z50

Karcoma fuel tap M12x1 vertical (with union nut) 2 connections

Manufacturer: Karcoma · Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Installation direction: vertical / vertical · Outlet direction: any · Spare tube shape: straight · Ø fuel hose connection: 6 mm · Reserve level: 50 mm · Thread type: MF12x1 (fine pitch thread) · Mounting type: Union nut

swiing® revival cable guide mudguard black | Puch

Manufacturer: swiing® revival parts · Material: Plastic · Total length: 74 mm · Color: black · Height: 12.5 mm · Hole spacing: 63 mm · Mounting type: Plug connection · Number of fixing points: 2 pcs

swiing® revival rubber grommet ignition | Puch X30 Z50

Manufacturer: swiing® revival parts · Material: Rubber · Total length: 19.3 mm · Ø Cable bushing: 2.5 mm · Ø Cable bushing: 5.2 mm · Color: black · Width: 15.6 mm · Height: 3.5 mm · Total height: 11.3 mm

Screw nipple M6 shift cable | Sachs 50/3, 50/4

Thread type: M6x1 (standard thread)

Bride cable original | Piaggio SI

Manufacturer: Piaggio · Ø mounting hole: 7.15 mm · Piaggio OEM number: 215997

Magura set screw M6x34 mm lock nut SW10

Slotted: No · Manufacturer: Magura · Ø cable holder: 3.05 mm · Material: Brass · Surface: nickel-plated · Total length: 34 mm · Width across flats Screw: 8 mm · Ø Receptacle: 7.05 mm · Thread type: M6x1 (standard thread) · Width across flats nut: 10 mm · Thread length: 23 mm

swiing® revival protective cap shift paddle black | Puch X30 Z50

Manufacturer: swiing® revival parts · Material: Plastic · Color: black

Petrol hose Ø 5 / 7 mm transparent 30 cm

Manufacturer: Made in Italy · Ø inside: 5 mm · Ø outside: 7 mm · Total length: 300 mm · Color: transparent

Cable routing Bowden cable

Material: Aluminum · Width: 20.5 mm · Ø inside: 0 - 8 mm
