Puch engine & gearbox

Oil seal NBR 16/28/7 BS Kickstarter | Puch Z50

Temperature resistance (min.): -30 - 100 °C · Simmering type: BS - With sheet metal outer casing / one sealing lip / one dust lip. · Ø inside: 16 mm · Ø outside: 28 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR

Gearshift engine Occ. | Z50

Manufacturer: Puch · Material: Steel · Surface: raw

Connecting rod bushing 10/12/13 bronze | Puch

Ø inside: 10 mm · Nominal diameter inside: 10 mm · Ø outside: 12 mm · Total height: 13 mm · Manufacturer: Puch · Material: special bearing bronze

GPO screw set for engine mounting Inox | Puch

Manufacturer: GPO · Material: Chrome steel (known as Nirosta®) · Drive: External hexagon · Screw head: Hexagon

swiing® ingenious spring gearshift (reinforced, +20%) Inox | Puch X30 Z50

Manufacturer: swiing® ingenious parts · Material: Chrome steel (known as Nirosta®)

swiing® revival spring gearshift Inox | Puch Velux

Spring design: Nose feather · Manufacturer: swiing® revival parts · Material: Chrome steel (known as Nirosta®) · Surface: electropolished · Area of application: Standard · Puch OEM number: 320.5.14.018.1

GPO oil filler plug gray | Puch Z50, ZA50

Manufacturer: GPO · Color: gray · Material: NBR · Total length: 25 mm · Ø mounting hole: 11 mm · Clamping diameter: 13 mm · Ø outside: 16.4 mm · Puch OEM number: 364.2.10.660.1

swiing® revival cylinder base gasket 38 mm 0.5 mm | Puch X30 Velux

Manufacturer: swiing® revival parts · Material: Oiled paper · Place of use: Cylinder base · Thickness: 0.5 mm · Ø cylinder: 38 mm

O-ring oil drain ZA50 large

Place of use: Outlet · Ø inside: 11 mm · Ø outside: 16 mm · Cord thickness: 2.5 mm · Color: black · Manufacturer: Puch · Puch OEM number: 901.3784

Connecting rod bushing reduction 10/14/12 bronze | Puch

Ø inside: 10 mm · Nominal diameter inside: 10 mm · Ø outside: 14 mm · Total height: 12 mm · Material: special bearing bronze

Clutch Surflex Puch Supermaxi E50 (long pads)

swiing® revival gearbox cover gasket | Puch Velux X30

Manufacturer: swiing® revival parts · Material: Sealing paper · Number of components: 1 pcs · Thickness: 0.4 mm · Number of fixing points: 7 pcs

Ignition cover Standard | Puch

Material: Steel · Surface: chrome-plated · Color: Chrome · Height: 48 mm · Ø outside: 130 mm · Ø inside: 125 mm · Number of fixing points: 2 pcs

Oil filler plug with sealing ring | Puch Maxi

Material: Steel · Surface: galvanized (blue) · Thread type: M10x1.5 (standard thread) · Drive: Slot · Screw head: Lens head · Ø External head: 14 mm · Total length: 14.6 mm · Thread length: 6 mm · Number of components: 2 pcs · Puch OEM number: 364.1.10.660.1

Oil seal NBR 22/40/7 AS crankshaft | E50

Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 22 mm · Ø outside: 40 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized

Oil seal NBR 17/40/7 A DUO | Puch E50

Temperature resistance (min.): -30 - 100 °C · Simmering type: A DUO - With rubberized outer casing / two sealing lips. · Ø inside: 17 mm · Ø outside: 40 mm · Width: 7 mm · Manufacturer: Puch · Material: NBR · Surface: rubberized · Area of application: Standard

Puch clutch cover ZA50 engine | Puch 30 NG-2AH

Manufacturer: Puch · Material: ABS plastic · Number of fixing points: 7 pcs

swiing® revival decoupling shaft | Puch X30 Velux old + new version

Manufacturer: swiing® revival parts · Surface: gas nitrided · Total length: 88.8 mm · Ø outside: 10 mm · Area of application: High End

Rubber washer starter shaft E50

Manufacturer: Puch · Material: Rubber · Color: black

Rubber kickstarter replica | Puch

Material: Rubber · Ø inside: 8.5 mm · Ø outside: 17.2 mm · Total length: 64 mm

Gasket cylinder base 2 mm | Puch

Material: Sealing carton · Place of use: Cylinder base · Thickness: 2 mm · Ø inside: 49 mm · Nominal diameter: 49 mm · Hole pattern [mm]: 44 x 44

Motor cable routing | Z50

Puch OEM number: 128.6305

Gilardoni italkit diaphragm seal | Puch

Manufacturer: Gilardoni italkit · Material: Sealing paper · Place of use: Admission · Thickness: 0.5 mm · Hole pattern [mm]: 34 x 60 · Area of application: Racing · Area of application: Tuning

Koyo 12.7/17.46/15.8 pinion shaft | Puch ZA50

Bearing type: Needle box · Dimension needle bearing: 12.7/17.5 x 15.7 · Ø inside: 12.7 mm · Ø outside: 17.5 mm · Manufacturer: Koyo · Width: 15.7 mm

swiing® revival engine seal | Puch Velux X30

Manufacturer: swiing® revival parts · Material: Sealing paper · Number of components: 1 pcs · Thickness: 0.4 mm · Number of fixing points: 9 pcs

Drive gear 69 teeth Occ. | Z50

Manufacturer: Puch · Toothing type: helical toothed · Number of teeth: 69 pcs

swiing® revival centering screw M22x1 galvanized | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Nut type: Hexagon nut · Thread type: MF22x1 (fine pitch thread) · Drive: External hexagon · Width across flats SW: 27 mm · Puch OEM number: 050.1.1233

O-ring oil drain ZA50 small

Place of use: Outlet · Cord thickness: 2.4 mm · Color: black · Manufacturer: Puch · Ø inside: 4.2 mm · Ø outside: 9 mm · Puch OEM number: 900.3797

Centering screw M22x1.5 plastic | Puch Z50

Material: Plastic · Nut type: Hexagon nut · Thread type: MF22x1.5 (fine pitch thread) · Drive: External hexagon · Puch OEM number: 329.1.12.133.1

HK Clutch "Racing" Kickstarter Aramid | Puch E50

Manufacturer: HK Clutches · Material: Steel · Material addition: Aluminum · Ø outside: 93 mm · Recording type: Cone mounting · Number of jaws: 3 pcs · Number of springs: 3 pcs · Ø inside: 13.6 mm · Ø inside: 14.6 mm · Thickness: 20.3 mm · Area of application: Racing

swiing® revival bearing press-on sleeve | Puch, Sachs

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Nominal diameter inside: 17.5 mm · Ø outside: 25 mm · Ø inside: 17.6 mm · Total length: 86 mm

Crescent ring decoupling shaft X30

Fuse type: Inside · Manufacturer: Puch · Place of use: Uncoupling shaft

NTN 6005 ball bearing 25/47/12 | ZA50 motor

Bearing type: Deep groove ball bearing · Stock number: 6005 · Ø inside: 25 mm · Ø outside: 47 mm · Width: 12 mm · Inner ring width: 12 mm · Manufacturer: NTN · Ball bearing closed: No · Bearing clearance: CM (special/noise-reduced) · Bearing cage: "-" Sheet steel cage ball-guided · Material: Steel · Area of application: Standard

NTN 6203 NR C3 ball bearing with outer ring (old model) | Puch E50

Bearing type: Deep groove ball bearing · Stock number: 6203 · Ø inside: 17 mm · Ø outside: 40 mm · Ø outside: 44 mm · Width: 12 mm · Inner ring width: 12 mm · Manufacturer: NTN · Ball bearing closed: No · Bearing clearance: C3 · Bearing cage: "-" Sheet steel cage ball-guided · Groove ring: Yes · Material: Steel · Surface: blank · Area of application: Standard

swiing® revival plain bearing clutch basket | Puch Z50

Ø inside: 15 mm · Nominal diameter inside: 15 mm · Ø outside: 17 mm · Total height: 16.2 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze

swiing® revival thrust washer 12.5/18/2 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 2 mm

swiing® revival thrust washer 12.5/18/2.5 gearbox | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: hardened & ground · Ø inside: 12.5 mm · Ø outside: 18 mm · Thickness: 2.5 mm

Rubber kickstarter original | Puch

Material: Rubber

swiing® revival plain bearing clutch basket | Puch E50

Ø inside: 15 mm · Nominal diameter inside: 15 mm · Ø outside: 17 mm · Total height: 21.75 mm · Manufacturer: swiing® revival parts · Material: special bearing bronze

swiing® revival clutch shaft Ø 14 mm | Puch E50

Manufacturer: swiing® revival parts · Total length: 79.2 mm · Ø outside: 13.95 mm · Area of application: Standard

swiing® revival gearbox cover gasket ZA50 engine | Puch Maxi S -2A, X30 NG - 2AH

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 175 mm · Width: 125 mm · Thickness: 0.3 mm · Number of fixing points: 6 pcs · Puch OEM number: 321.1.10.649.1

Jasil connecting rod | Puch

Manufacturer: Jasil · Material: Steel · Surface: copper-coated · Connecting rod length center-center: 90 mm · Total length: 114.5 mm · Ø piston pin (B): 12 mm · Ø Connecting rod bolt: 14 mm · Ø lower connecting rod eye outside: 24.6 mm · Ø upper connecting rod eye outside: 20.9 mm · Ø lower bearing inside: 18 mm · Ø inside upper bearing: 15 mm · Dimension lower bearing: 14/15 x 9.75 mm · Dimension upper bearing: 12/15 x 14.7 mm · Connecting rod pin length: 34 mm · Thickness: 10 mm · Area of application: Standard · Area of application: Tuning

swiing® revival fitting sleeve engine housing | Puch Z50

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Total length: 20 mm · Ø outside: 10 mm

swiing® revival gasket set engine | Puch Maxi S - 2A (ZA50 engine)

Manufacturer: swiing® revival parts · Area of application: Standard · Hole spacing inlet: 32 - 38 mm · Ø outlet inside: 22 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 · Number of components: 10 pcs

GPO screw set for engine mounting, galvanized | Puch

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Thread type: M8x1.25 (standard thread) · Drive: External hexagon · Screw head: Hexagon · Width across flats SW: 13 mm · Thread length: 23.5 mm · Shank: Yes · Strength class: 8.8 · Storage method: Sack · Dimension storage box: 100 x 90 x 10 · Number of components: 12 pcs · Color: silver

Shim 17/25/0.2 Crankshaft L17 Bearing | Puch

Ø inside: 17 mm · Nominal diameter inside: 17 mm · Ø outside: 25 mm · Thickness: 0.2 mm · Manufacturer: Puch · Material: Steel · Surface: blank / oiled

swiing® revival gearbox cover gasket | Puch Maxi S LG2 ZA50 engine

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Total length: 175 mm · Width: 133 mm · Thickness: 0.3 mm · Number of fixing points: 6 pcs

Starter cable in engine | Puch ZA50

Ø Stranded wire: 1.5 mm · Cable length: 68 mm · Nipple shape: Barrel (transverse) · Ø nipple: 6 mm · Nipple length: 8 mm · Manufacturer: Made in Austria · Puch OEM number: 910.4.18.001.0

Jasil crankshaft | Puch 3- & 4-speed models

Manufacturer: Jasil · Total length of crankpin on clutch side: 73 mm · Number of gears: 3 pcs · Number of gears: 4 pcs · Area of application: Standard

swiing oil drain plug | Puch ZA50

Manufacturer: swiing · Material: Steel · Surface: galvanized (blue) · Screw head: Hexagon · Drive: External hexagon · Puch OEM number: 321.1.10.670.1
