Parmakit piston 45 mm #B | Puch

GPO 45 mm cylinder head tuning | Puch Maxi S, N / X30 NS, NL, N-2AH

Manufacturer: GPO · Camouflaged: Yes · Surface: sandblasted · Material: Aluminum · Ø cylinder: 45 mm · Total length: 135 mm · Width: 125 mm · Height: 55 mm · Hole pattern [mm]: 44 x 44 · Candle thread: short · Number of fixing points: 4 pcs · Area of application: Tuning · Decompressor: No

Motorex 2-stroke oil "POWER SYNT" fully synthetic 1 L

Manufacturer: Motorex · Oil type: fully synthetic · Contents: 1000 ml · Color: red

Buzzetti pliers for piston ring assembly

Manufacturer: Buzzetti · Area of application: (Dis)assembly tool

Motorex 2-stroke oil semi-synthetic 1 L (for running in cylinders)

Manufacturer: Motorex · Oil type: semi-synthetic · Contents: 1000 ml · Color: green

GPO piston pin extractor Ø 10, 12, 14 mm

Manufacturer: GPO · Surface: burnished · Number of components: 7 pcs · Diameter: 10 mm · Diameter: 12 mm · Diameter: 14 mm · Material: Steel · Total length: 130 mm · Width across flats: 10 mm · Width across flats: 17 mm · Area of application: (Dis)assembly tool

Parmakit 45 mm cylinder kit (large ribs) | Puch

Manufacturer: Parmakit · Camouflaged: No · Surface: sandblasted · Displacement: 70 ccm · Material: Aluminum · Crankshaft stroke: 43 mm · Nominal diameter: 45 mm · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 44 x 44 · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs · Area of application: Tuning · Thread outlet: M6x1 (standard thread)

Parmakit 45 mm cylinder kit 70 ccm camouflaged | Puch

Manufacturer: Parmakit · Camouflaged: No · Surface: sandblasted · Displacement: 70 ccm · Material: Aluminum · Crankshaft stroke: 43 mm · Nominal diameter: 45 mm · Ø cylinder neck: 47.8 mm · Ø outlet inside: 26.5 mm · Hole spacing inlet: 38 mm · Inlet window: 23.7 x 15 mm · Thread inlet: M6x1 (standard thread) · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs · Area of application: Tuning · Outlet type: straight · Thread outlet: M6x1 (standard thread) · Decompressor: No

Parmakit piston 45 mm #C | Puch

Manufacturer: Parmakit · Ø outside piston (A): 44.95 mm · Compression height (C): 22.45 mm · Curvature (D): 4.5 mm · Total piston height (E): 53.98 mm · Number of piston rings (F): 1 pcs · Nominal diameter: 45 mm · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Ø piston pin (B): 12 mm · Tolerance group: C · Weight piston kit: 97 g

Parmakit piston ring 45 mm | Puch / Tomos

Manufacturer: Parmakit · Nominal diameter: 45 mm · Piston ring impact: Internal fuse (IS)

Parmakit piston 45 mm #A | Puch

Manufacturer: Parmakit · Ø outside piston (A): 44.93 mm · Compression height (C): 21.5 mm · Curvature (D): 3.83 mm · Total piston height (E): 52.3 mm · Number of piston rings (F): 1 pcs · Nominal diameter: 45 mm · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Ø piston pin (B): 12 mm · Tolerance group: A · Weight piston kit: 98 g

GPO 45 mm cylinder head tuning new version | Puch (AT)

Manufacturer: GPO · Material: Aluminum · Ø cylinder: 45 mm · Total length: 135 mm · Width: 140 mm · Height: 55 mm · Number of fixing points: 4 pcs · Area of application: Tuning · Decompressor: No

Outlet seal Ø 27 Steel ring

Place of use: Outlet · Material: Sealing carton · Material: Sheet metal (steel) · Reinforced: Yes · Ø outlet inside: 27 mm · Thickness: 2.1 mm · Hole spacing outlet: 42.5 mm · Area of application: Tuning · Ø screw holder: 6.3 mm

Jasil crankshaft | Sachs 503 AB-CH / ABL CH (A2901 / A2902)

Dimension needle bearing: 12 / 15 x 12.8 mm (axe 12) · Manufacturer: Jasil · Thread type: MF10x1 (fine pitch thread) · Cheek type: standard · Material: Steel · Crankshaft stroke: 42 mm · Connecting rod length center-center: 84 mm · Number of gears: 2 pcs · Thread length: 11 mm · Total length of crankpin on clutch side: 101.15 mm · Total length crankpin ignition side: 64.1 mm · Ø crank webs: 85 mm · Ø Connecting rod eye: 15 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 15 mm · Weight: 875 g · Ø Bearing seat (ignition side): 15 mm · Area of application: Standard · Wide crank webs: 30.3 mm · Length 1st paragraph: 19 mm · Length 2nd paragraph: 51 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 14 mm · Ø 3rd step (on the clutch side): 8 mm · Length of shoulder (ignition side): 34 mm · Alternative version of the Pony OEM number: A2900 · Pony OEM number: A2901 · Pony OEM number: A2902 · Alternative version of the Sachs OEM number: 0288 115 002 · Alternative version of the Sachs OEM number: 0288 115 102

Parmakit gasket set 45 mm | Puch

Manufacturer: Parmakit · Number of components: 4 pcs · Ø cylinder: 45 mm · Hole pattern [mm]: 44 x 44 mm · Area of application: Tuning · Decompressor: No
