Sealing cord air filter Sachs 535 Cat (A3315)

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Contents: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Area of application: Gearbox lubrication with clutch · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

BING rubber grommet Ø 8 mm carburetor pipe bend

Manufacturer: BING · Material: Rubber · Clamping diameter: 4 mm · Ø inside: 8 mm · Total length: 29 mm · Ø outside: 12 mm · Color: black · Alternative version of the Pony OEM number: A1930 · Pony OEM number: A1952 · Alternative version of the Sachs OEM number: 0260 024 001 · Sachs OEM no.: 0260 125 000

GPO gasket set carburetor Bing SRE

Thickness: 0.5 mm · Thickness: 0.9 mm · Thickness: 1.5 mm · Manufacturer: GPO · Ø outside: 12.2 mm · Ø outside: 45 mm · Material: Sealing paper · Component group Carburetor: Sealing, revising · Carburetor type: SRE · Ø inside: 7.8 mm · Ø inside: 41 mm · Camouflaged: No

Meteor piston 38 mm #B | Sachs 503 AB/AC

Nominal diameter: 38 mm · Manufacturer: Meteor · Ø outside piston (A): 37.97 mm · Compression height (C): 28 mm · Curvature (D): 2 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Ø piston pin (B): 12 mm · Tolerance group: B · Weight piston kit: 75 g · Pony OEM number: A5685B · Sachs OEM no.: 0286 382 306

NSK BO15 shoulder ball bearing 15/40/10 (A4502)

Bearing cage: Brass cage ball-guided · Inner ring width: 10 mm · Manufacturer: NSK · Ø outside: 40 mm · Material: Brass · Material: Steel · Surface: blank · Stock number: BO15 · Bearing type: Shoulder bearing · Width: 10 mm · Ø inside: 15 mm · Ball bearing closed: No · Area of application: Standard · Pony OEM number: A4502 · Sachs OEM no.: 0932 007 001

NSK 6201 ball bearing 12/32/10

Bearing cage: Sheet steel cage ball-guided · Inner ring width: 10 mm · Manufacturer: NSK · Ø outside: 32 mm · Bearing clearance: CM (special/noise-reduced) · Groove ring: No · Material: Steel · Surface: blank · Stock number: 6201 · Bearing type: Shoulder bearing · Width: 10 mm · Ø inside: 12 mm · Ball bearing closed: No · Area of application: Standard

Shaft seal NBR 14.96x31.5x3.5 Pinion shaft | Sachs 502, 50/2, 503 (A1134)

Manufacturer: Sachs · Ø outside: 31.5 mm · Material: NBR · Surface: coated · Width: 3.5 mm · Ø inside: 14.96 mm · Place of use: Pinion shaft · Temperature resistance (min.): -30 - 100 °C · Area of application: Standard · Pony OEM number: A1134 · Sachs OEM no.: 0230 011 100 · Sachs OEM no.: 0230 011 200

NTN 608 Ball bearing 8/22/7

Bearing cage: Sheet steel cage ball-guided · Inner ring width: 7 mm · Manufacturer: NTN · Ø outside: 22 mm · Bearing clearance: CN (standard) · Stock number: 608 · Bearing type: Deep groove ball bearing · Width: 7 mm · Ø inside: 8 mm

Oil seal NBR 15/30/5.5 A crankshaft | Sachs (A4215 & A5602)

Shaft seal type: A - With rubberized outer part / one sealing lip. · Manufacturer: Sachs · Ø outside: 30 mm · Material: NBR · Surface: rubberized · Width: 5.5 mm · Ø inside: 15 mm · Place of use: Crankshaft · Temperature resistance (min.): -30 - 100 °C · Pony OEM number: A5602 · Sachs OEM no.: 0230 111 100

GPO chain tensioning roller (loose)

Color: black · Ø mounting hole: 12.25 mm · Manufacturer: GPO · Material: Plastic · Ø outside chain roller: 40 mm · Width: 19 mm · Number of fixing points: 1 pcs
