swiing® ingenious 15 mm intake manifold long version | Sachs 503 2AL, 2BL

Magura set screw M6 x 34 lock nut SW8

Total length: 34 mm · Slotted: No · Width across flats Screw: 8 mm · Manufacturer: Magura · Material: Brass · Material: Steel · Surface: galvanized (blue) · Surface: nickel-plated · Ø cable holder: 3.05 mm · Ø Receptacle: 7.05 mm · Thread type: M6x1 (standard thread) · Width across flats nut: 8 mm · Thread length: 24 mm

swiing® revival special nut M6 SW8 (sprocket ref. back pedal / intake manifold)

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Nut type: Hexagon nut · Drive: External hexagon · Thread type: M6x1 (standard thread) · Width across flats: 8 mm · Height: 6 mm

swiing® ingenious 15 mm carburetor camouflaged | Sachs 503

Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Tuning · Camouflaged: Yes · Component group Carburetor: Carburetor complete · Width: 50 mm · Carburetor type: SRE · Height: 95 mm · Nominal diameter: 15 mm · Total length: 66 mm · Nozzle thread: M3.5x0.6 (standard thread) · Ø fuel hose connection: 6 mm · Nozzle size: 62 · Ø Inside entrance: 15 mm · Ø Internal connection: 20 mm · Ø Output inside: 15 mm · Mounting type: Plug connection clamped · Ø Air filter connection: 20 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle block: 2.17 · Clamping screw torque (max.): 4 N/m

swiing® ingenious tuning cylinder 40 mm | Sachs 503

Manufacturer: swiing® ingenious parts · Material: Aluminum · Camouflaged: No · Area of application: Tuning · Surface: sandblasted · Crankshaft stroke: 42 mm · Displacement: 55 ccm · Nominal diameter: 40 mm · Number of fixing points: 4 pcs · Hole spacing inlet: 32 mm · Ø piston pin (B): 12 mm · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 60 x 40 / 37 x 37 · Outlet type: clamped · Decompressor: No

NGK B8HS spark plug short thread

Manufacturer: NGK · Candle thread type: short · Spark plug socket: M4 · Spark plug socket: SAE · Suppressed: No · Thread type: MF14x1.25 (fine pitch thread) · Width across flats: 21 mm

swiing® revival solid exhaust clamp 26 - 28 mm galvanized (12.9 strength)

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Ø outside: 39 mm · Ø inside: 26 - 28 mm · Mounting type: Nuts & bolts · Width: 42 mm · Material thickness: 1.5 mm

Exhaust clamp 70 mm chrome wide version.

Manufacturer: Made in Portugal · Material: Steel · Surface: chrome-plated · Nominal diameter: 70 mm · Ø mounting hole: 8.2 mm · Thickness: 2 mm · Clamping diameter: 67 - 71 mm · Width: 28 mm · Number of fixing points: 1 pcs · Color: Chrome

swiing® ingenious 15 mm carburetor camouflaged | Sachs 503

Manufacturer: swiing® ingenious parts · Material: Aluminum · Area of application: Tuning · Camouflaged: Yes · Component group Carburetor: Carburetor complete · Width: 50 mm · Carburetor type: SRE · Height: 95 mm · Nominal diameter: 15 mm · Total length: 66 mm · Nozzle thread: M3.5x0.6 (standard thread) · Ø fuel hose connection: 6 mm · Nozzle size: 62 · Ø Inside entrance: 15 mm · Ø Internal connection: 20 mm · Ø Output inside: 15 mm · Mounting type: Plug connection clamped · Ø Air filter connection: 20 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Nozzle block: 2.17 · Clamping screw torque (max.): 4 N/m

swiing® revival air filter Racing | Sachs 503

Manufacturer: swiing® revival parts · Material: Plastic · Color: black · Filter type: Racing screen · Width: 68 mm · Ø Internal connection: 20 mm · Mounting type: Plug connection clamped · Total length: 165 mm · Height: 52 mm · Camouflaged: No · Area of application: Tuning

swiing® ingenious exhaust manifold 28 mm chrome | Sachs 503

Manufacturer: swiing® ingenious parts · Material: Steel · Surface: chrome-plated · Color: Chrome · Ø outside: 28 mm · Ø inside: 26 mm · Total length: 410 mm · Mounting type: Bride · Flame tube attachment: inserted

GPO piston 40.94 mm | Sachs 502, 50/2, 50/3, 50/4

Nominal diameter: 41 mm · Manufacturer: GPO · Thick piston ring: 1.8 mm · Ø outside piston (A): 40.94 mm · Compression height (C): 28 mm · Curvature (D): 3.2 mm · Total piston height (E): 49.4 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Ø piston pin (B): 12 mm · Weight piston kit: 86 g

swiing® ingenious 15mm carburetor set HG long | Sachs 503

Total length: 66 mm · Total length: 165 mm · Manufacturer: swiing® ingenious parts · Camouflaged: No · Area of application: Tuning · Component group Carburetor: Carburetor complete · Carburetor type: SRE · Nominal diameter: 15 mm · Ø Internal connection: 20 mm · Ø Inside entrance: 15 mm · Width: 50 mm · Width: 68 mm · Mounting type: Flange · Mounting type: Plug connection clamped · Ø Output inside: 15 mm · Height: 52 mm · Height: 95 mm · Ø Air filter connection: 20 mm · Ø fuel hose connection: 6 mm · Mixed oil connection: No · Vacuum connection: No · Choke control: Hand choke · Color: black · Nozzle thread: M3.5x0.6 (standard thread) · Nozzle block: 2.17 · Nozzle size: 62 · Hole spacing inlet: 32 mm · Clamping screw torque (max.): 4 N/m

AKOA 41 mm cylinder head | Sachs 503 2AL, AAL, 2BL, ABL

Manufacturer: AKOA · Material: Aluminum · Area of application: Tuning · Ø cylinder: 41 mm · Height: 30 mm · Candle thread: short · Number of fixing points: 4 pcs · Hole pattern [mm]: 37 x 37 · Decompressor: No

GPO gasket set 41 mm "Pomodoro" | Sachs 503

Manufacturer: GPO · Material: Aluminum · Material: Sealing carton · Material: Sealing paper · Ø cylinder: 41 mm · Thickness: 0.3 mm · Thickness: 1 mm · Number of components: 3 pcs · Hole spacing inlet: 0 - 32 mm
