Intake flange 16 mm Malossi MP-One housing | Piaggio SI, Boxer

Dell'Orto 16/16 SHA carburetor hand choke

Nominal diameter: 16 mm · Manufacturer: Dell'Orto · Material: Aluminum · Camouflaged: No · Component group Carburetor: Carburetor complete · Area of application: Tuning · Color: black · Carburetor type: SHA · Choke control: Hand choke · Total length: 82 mm · Nozzle thread: M5x0.8 (standard thread) · Ø fuel hose connection: 5.1 mm · Ø fuel hose connection: 6 mm · Ø without reducing sleeve: 21 mm · Nozzle size: 82 · Ø Inside entrance: 16 mm · Ø Internal connection: 19 mm · Width: 72 mm · Ø Output inside: 16 mm · Ø Air filter connection: 56 mm · Ø Air filter connection: 58.5 mm · Height: 111 mm · Mixed oil connection: No · Vacuum connection: No · Mounting type: Plug connection clamped

Dell'Orto 15/15 SHA carburetor hand choke (with air filter)

Nominal diameter: 15 mm · Manufacturer: Dell'Orto · Material: Aluminum · Camouflaged: No · Component group Carburetor: Carburetor complete · Area of application: Racing · Area of application: Tuning · Color: black · Carburetor type: SHA · Choke control: Hand choke · Total length: 82 mm · Nozzle thread: M5x0.8 (standard thread) · Ø fuel hose connection: 5.3 mm · Ø fuel hose connection: 6 mm · Ø without reducing sleeve: 21 mm · Nozzle size: 68 · Ø Inside entrance: 15 mm · Ø Internal connection: 18 mm · Width: 70 mm · Ø Output inside: 15 mm · Ø Air filter connection: 59 mm · Height: 100 mm · Mixed oil connection: No · Vacuum connection: No · Mounting type: Plug connection clamped

Malossi MP-One engine case breaker ignition | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Malossi · Material: Aluminum · Surface: sandblasted · Ø inside: 24 mm · Width: 104 mm · Total length: 220 mm · Color: silver · Ignition type: Breaker · Height: 174 mm

Malossi MP-One engine case electronic ignition | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Malossi · Material: Aluminum · Surface: sandblasted · Color: silver · Ignition type: Electronic · Ø inside: 24 mm · Width: 104 mm · Ø outside: 140 mm · Height: 174 mm · Total length: 220 mm

19 mm intake flange engine case Malossi MP-One | Piaggio

Material: Aluminum · Ø inside: 19 mm · Mounting type: Screws · Number of fixing points: 3 pcs · Ø External connection: 24 mm · Area of application: Tuning

Malossi intake manifold 21 mm MP-One CNC | Piaggio SI, Bravo, Boxer

Manufacturer: Malossi · Material: Aluminum · Material: Rubber · Ø inside: 21 mm · Mounting type: Screws · Number of fixing points: 3 pcs · Ø External connection: 25 mm · Area of application: Tuning

Malossi 47 mm cylinder kit BIG DEPS 4 MHR incl. head 12 mm KoBo | Piaggio Ciao, SI, Bravo, Boxer

Nominal diameter: 47 mm · Manufacturer: Malossi · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Crankshaft stroke: 43 mm · Displacement: 75 ccm · Ø Outlet outside: 22 mm · Ø Outlet outside: 27 mm · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Outlet type: clamped · Decompressor: Yes · Area of application: High End

SKF Bearing Set & Oil Seal Engine | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: SKF · Material: Plastic · Material: Steel · Number of components: 3 pcs · Area of application: Standard

Decompressor set | Piaggio Ciao, Bravo, Boxer

Material: Spring steel · Material: Steel · Surface: blank · Surface: galvanized (blue) · Total length: 75 mm · Area of application: Standard

Malossi 46.5 mm cylinder kit without head 10 mm KoBo | Piaggio Ciao, SI, Bravo, Boxer

Nominal diameter: 46.5 mm · Manufacturer: Malossi · Material: Gray cast iron · Camouflaged: No · Surface: sandblasted · Area of application: Tuning · Crankshaft stroke: 43 mm · Displacement: 73 ccm · Ø cylinder neck: 50 mm · Ø Outlet outside: 22.4 mm · Ø outlet inside: 18.1 mm · Ø piston pin (B): 10 mm · Hole pattern [mm]: 55 x 34 · Number of fixing points: 3 pcs · Outlet type: clamped · Decompressor: Yes

Malossi 46.5 mm cylinder kit without head 12 mm KoBo | Piaggio Ciao, SI, Bravo, Boxer

Nominal diameter: 46.5 mm · Manufacturer: Malossi · Material: Gray cast iron · Camouflaged: No · Surface: sandblasted · Crankshaft stroke: 43 mm · Displacement: 73 ccm · Ø cylinder neck: 50 mm · Ø Outlet outside: 22.4 mm · Ø outlet inside: 18.1 mm · Number of fixing points: 3 pcs · Ø piston pin (B): 12 mm · Hole pattern [mm]: 55 x 34 · Outlet type: clamped · Decompressor: Yes · Area of application: Tuning

Wedge 12.1x4.9x3 mm

Material: Steel · Total length: 12.5 mm · Height: 4.9 mm · Width: 3 mm

Malossi MP-One engine case breaker ignition | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Malossi · Material: Aluminum · Surface: sandblasted · Ø inside: 24 mm · Width: 104 mm · Total length: 220 mm · Color: silver · Ignition type: Breaker · Height: 174 mm

Malossi MP-One engine case electronic ignition | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Malossi · Material: Aluminum · Surface: sandblasted · Color: silver · Ignition type: Electronic · Ø inside: 24 mm · Width: 104 mm · Ø outside: 140 mm · Height: 174 mm · Total length: 220 mm

Malossi gasket set racing case | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Malossi · Area of application: Tuning · Number of components: 3 pcs

GPO Electronic ignition 12V | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Light coil voltage: 12 V · Performance: 90 W · Direction of rotation: right · Mounting type: Screws · Number of fixing points: 3 pcs · Area of application: Original · Area of application: Standard · Piaggio OEM number: 181103 · Piaggio OEM number: 219965 · Piaggio OEM number: 244127

GPO flywheel 800 g rotary valve shaft electronic ignition | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: GPO · Material: Aluminum · Ø Internal flywheel: 106 mm · Thread type: MF17x1 (fine pitch thread) · Direction of rotation: right · Ø Flywheel outside: 139.5 mm · Weight: 800 g · Piaggio OEM number: 181103 · Piaggio OEM number: 2238183
